Shank Diameter: 3.175mm
Total Length: ~ 38mm
Material: Solid Carbide
Materials:
Wood, Plastics, Composite materials, Non-Ferrous Metal, etc.
Tool Reference Parameters:
* RPM: SpindleSpeed(RPM) / Feed: FeedRate(mm/min)
PFeed: PlungeFeedRate(mm/min) / DOC: Depth of Cut(mm)
| Tools | Aluminum | Brass | Carbon Fiber | Copper | Hardwood | PCB | Plastic | Softwood |
|---|---|---|---|---|---|---|---|---|
| 0.1mm*90° Chamfering |
RPM:12000 Feed:600 PFeed:200 DOC:0.2 |
RPM:12000 Feed:500 PFeed:200 DOC:0.1 |
RPM:12000 Feed:500 PFeed:200 DOC:0.1 |
RPM:12000 Feed:500 PFeed:200 DOC:0.1 |
RPM:12000 Feed:1000 PFeed:500 DOC:1 |
RPM:12000 Feed:500 PFeed:200 DOC:0.1 |
RPM:12000 Feed:1000 PFeed:500 DOC:1 |
RPM:12000 Feed:1200 PFeed:500 DOC:2 |
